interCAD® EzLibrary
ECAD Library Creator Logical Symbol Footprint/Cell/Decal
interCAD® EzLibrary
interCAD EzLibrary is the software which can automatically create ECAD library of relevant parts
by inputting information about forms of circuit components.
Also, it can create the standard library without both human errors and library development deviation among development engineers.
Create a standard ECAD library in an easy and fast way with amazing automation tools.
Create Logical Symbol
Introduce
EzLibrary is a program creating the symbol data of ECAD circuit in an easy and fast way. Using an excel pin information received from the component suppliers, it can create the symbol of circuit matching the customers' standard. Also, it provides DRC function to verify errors.
Main Function
Importing Excel Component Pin's no./name
Easy and Quick Typing Component Pin's no./ name
Providing Symbol Preview Screen
Automatic Standard Symbol Property Generation
Automatic Standard Logical Symbol
DRC Function
Pin no./name Error Verification
Symbol Redundancy Verification
Creating Footprint / Cell/ Decal
Introduce
It allows you to automatically create ECAD footprint by inputting an electronic component's size and form. Also, it can create the customer's standard footprint without both human errors and development deviation among library developers.
Main Function
Providing UI for Intuitive Component's Information Input
Providing Footprint Preview Screen
Automatic Standard Footprint Property Generation
Automatic Standard Footprint Generation
Managing Database of Footprint's Standard
DRC Function
Verifying Pin/Pad Space
Verifying Errors of Size Information
Footprint Redundancy Verification
Customized Product
Software Designed to Meet Customer' Needs
Existing EDA products don't provide the customized function revisions and additional development even though function revisions and additional development for software usage are necessary since the standard and all using components by each customer are different in ECAD library case.
However, interCAD EzLibrary provides functions revisions and additional development needed customers' library standard either for free or at a cost.
